Netwerk
Maximale overdrachtssnelheid van gegevens
1000 Mbit/s
Netwerkstandaard
IEEE 802.1as, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Bekabelingstechnologie
10/100/1000BaseT(X)
Ethernet LAN, data-overdrachtsnelheden
10, 100, 10, 100, 1000 Mbit/s
Koperen ethernetbekabelingstechnologie
1000BASE-T, 100BASE-TX, 10BASE-T
LAN controller
Intel® I350
Ondersteunde netwerkprotocollen
TCP, UDP, IP
Overige specificaties
Ethernet-adapter ARK ID
84805
PCI-SIG* SR-IOV Capable
Ja
Soort kabel
Cat 5 up to 100m
Export Control Classification Number (ECCN)
5A991
Commodity Classification Automated Tracking System (CCATS)
NA
Intel® Virtual Machine Device Queues (VMDq)
Ja
Intel® Trusted Execution Technology
Nee
On-chip QoS and Traffic Management
Ja
Ingebouwde opties beschikbaar
Nee
Bericht signaal onderbroken
Nee
Intel® Flexible Port Partitioning
Ja
Snelheid en sleuf breedte
5.0 GT/s, x4 Lane
Lage halogeen opties beschikbaar
Nee
Fiber Channel over Ethernet
Nee
Intel® Ethernet Power Management
Ja
Intel® Data Direct I/O Technology
Nee
Intel® Virtualization Technology for Connectivity (VT-c)
Ja
Soort aansluiting
PCIe 2.1 (5.0GT/s)
Type product
Network Interface Card
Thermal Design Power (TDP)
5 W
Processorfamilie
Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE)
Optische drivecontroller
Intel I350
Bekabelingstype
Cat 5 up to 100m
Brackethoogte
Low-Profile (LP) / Full-Height (FH)
Opslag via ethernet
iSCSI, NFS
Kaartkabeldrager netwerkinterface
Koper
Kaarttype netwerkinterface
Server
URL productsamenvatting
http://www.intel.com/content/www/us/en/ethernet-controllers/ethernet-i350-server-adapter-brief.html?wapkw=i350
Laatste wijziging
63903513
Productfamilie
Intel Gigabit server adapter
Productnaam
Intel Ethernet Server Adapter I350-T4V2
Productcodenaam
Powerville
Minimale systeemeisen
Compatibele besturingssystemen
https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html
Ondersteunt Linux
RedHat EL Linux 5.0, RedHat EL Linux 6.0, SuSE Linux 10, SuSE Linux 11
Ondersteunde server operating systems
Windows Server 2003 R2, Windows Server 2008 R2
